Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: Four high tensile steel wire spiral layers
Cover: Abrasion, ozone and weather resistant synthetic rubber
Temperature:
-40°C to +100°C
Application:
Petroleum based hydraulic fluid, gasoline, water, diesel fuels, lubricating oils, glycol, mineral oils, and more.
| Hose ID | Hose O.D. | Working Pressure | Min. Burst Pressure | Min. Bend Radius | Length | Weight | ||||||
| In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | kg/m | lb/ft |
| 3/8 | 9.5 | 0.8 | 20.2 | 4568 | 31.5 | 18272 | 126 | 4.9 | 125 | 20/40 | 0.71 | 0.48 |
| 1/2 | 12.7 | 0.91 | 23 | 4060 | 28 | 16000 | 112 | 7.1 | 180 | 20/40 | 0.85 | 0.57 |
| 3/4 | 19 | 1.22 | 31 | 3045 | 21 | 16240 | 84 | 9.4 | 240 | 20/40 | 1.58 | 1.07 |
| 1 | 25.4 | 1.48 | 37.6 | 3045 | 21 | 16240 | 84 | 11.8 | 300 | 20/40 | 2.01 | 1.36 |
| 1 1/4 | 31.8 | 1.79 | 45.4 | 2538 | 17.5 | 10152 | 70 | 16.5 | 420 | 20/40 | 2.68 | 1.81 |
| 1 1/2 | 38.1 | 2.06 | 52.4 | 2030 | 14 | 8120 | 56 | 19.7 | 500 | 20/40 | 3.3 | 2.23 |
| 2 | 50.8 | 2.63 | 66.8 | 2030 | 14 | 8120 | 56 | 24.8 | 660 | 20/40 | 4.37 | 2.95 |
