Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: High tensile cords and helix steel wire
Cover: Oil and weather resistant synthetic rubber
Temperature:
-40°C to +100°C
Application:
Petroleum based hydraulic fluid, gasoline, water, diesel fuels, lubricating oils, glycol, mineral oils, and more.
Hose ID | Hose O.D. | Working | Burst | Bend | Length | Weight | |||
Pressure | Pressure | Radius | |||||||
In. | mm | mm | psi | MPa | psi | MPa | mm | m | kg/m |
3/4 | 19 | 34.9 | 305 | 2.1 | 1210 | 8.4 | 125 | 40/60 | 0.92 |
1 | 25 | 41.3 | 250 | 1.7 | 1015 | 7 | 150 | 40/60 | 1.1 |
1 1/4 | 32 | 50.8 | 200 | 1.4 | 810 | 5.6 | 200 | 40/60 | 1.3 |
1 1/2 | 38 | 57.2 | 150 | 1.05 | 610 | 4.2 | 255 | 40/60 | 1.8 |
2 | 51 | 69.9 | 100 | 0.7 | 410 | 2.8 | 300 | 40/60 | 2.23 |
2 1/2 | 63 | 82.6 | 60 | 0.4 | 250 | 1.7 | 355 | 40/60 | 3.23 |
3 | 76 | 95.3 | 60 | 0.4 | 230 | 1.6 | 460 | 40/60 | 4.25 |
3 1/2 | 89 | 107.9 | 40 | 0.3 | 180 | 1.25 | 530 | 40/60 | 5.05 |
4 | 102 | 120.7 | 40 | 0.25 | 145 | 1 | 610 | 40/60 | 5.6 |
