Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: One or two high tensile steel wire braids
Cover: Oil and weather resistant synthetic rubber
Temperature:
-40°C to +121°C
Application:
Petroleum based hydraulic fluid, gasoline, water, diesel fuels, lubricating oils, glycol, mineral oils, and more.
Hose ID | Hose O.D. | Working Pressure | Min. Burst | Min. Bend | Length | Weight | ||||||
Pressure | Radius | |||||||||||
In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | kg/m | lb/ft |
1/4 | 6.4 | 0.5 | 12.7 | 3045 | 21 | 12180 | 84 | 1.5 | 38.1 | 50/100 | 0.21 | 0.14 |
5/16 | 7.9 | 0.56 | 14.2 | 3045 | 21 | 12180 | 84 | 1.8 | 45.7 | 50/100 | 0.25 | 0.17 |
3/8 | 9.5 | 0.63 | 16 | 3045 | 21 | 12180 | 84 | 2 | 50.8 | 50/100 | 0.31 | 0.21 |
1/2 | 12.7 | 0.8 | 20.4 | 3045 | 21 | 12180 | 84 | 2.8 | 71.1 | 50/100 | 0.57 | 0.39 |
5/8 | 15.9 | 0.97 | 24.6 | 3045 | 21 | 12180 | 84 | 3 | 76.2 | 50/100 | 0.75 | 0.51 |
3/4 | 19 | 1.09 | 27.8 | 3045 | 21 | 12180 | 84 | 3.8 | 96.5 | 50 | 0.92 | 0.62 |
1 | 25.4 | 1.39 | 35.4 | 3045 | 21 | 12180 | 84 | 4.5 | 114.3 | 50 | 1.35 | 0.91 |
