Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: One or two high tensile steel wire braids
Cover: Oil and weather resistant synthetic rubber
Temperature:
-40°C to +121°C
Application:
Petroleum based hydraulic fluid, gasoline, water, diesel fuels, lubricating oils, glycol, mineral oils, and more.
Hose ID | Hose O.D. | Working Pressure | Min. Burst | Min. Bend | Length | Weight | ||||||
Pressure | Radius | |||||||||||
In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | kg/m | lb/ft |
1/4 | 6.4 | 0.53 | 13.5 | 5800 | 40 | 23200 | 160 | 1.5 | 38.1 | 50/100 | 0.31 | 0.21 |
5/16 | 7.9 | 0.6 | 15.3 | 5075 | 35 | 20300 | 140 | 1.8 | 45.7 | 50/100 | 0.37 | 0.25 |
3/8 | 9.5 | 0.71 | 18 | 4785 | 33 | 19140 | 132 | 2 | 50.8 | 50/100 | 0.47 | 0.32 |
1/2 | 12.7 | 0.83 | 21.1 | 3990 | 27.5 | 15950 | 110 | 2.8 | 71.1 | 50/100 | 0.6 | 0.41 |
5/8 | 15.9 | 0.97 | 24.7 | 3625 | 25 | 14500 | 100 | 3 | 76.2 | 50/100 | 0.73 | 0.49 |
3/4 | 19 | 1.1 | 28 | 3120 | 21.5 | 12470 | 86 | 3.8 | 96.5 | 50 | 0.87 | 0.59 |
1 | 25.4 | 1.4 | 35.6 | 2395 | 16.5 | 9570 | 66 | 4.5 | 114.3 | 50 | 1.38 | 0.93 |
1 1/4 | 31.8 | 1.71 | 43.5 | 1815 | 12.5 | 7250 | 50 | 5.9 | 150 | 50 | 1.78 | 1.2 |
