Tube:
Black Smooth Rubber
Reinforcement:
High textile plies,helix wire embedded
Cover:
Black,smooth rubber,weather and abrasion resistant,Fabric impression.
Temp Range:
-20℃ to 80℃
Application:
Mandrel built, suitable for water and non corrosive fluids.Suitable for agricultural purposes,industries and public works.
Inside | Outside Diameter | Working | Burst | Nominal | Bending Radius | Length | |||
Diameter | Pressure | Pressure | Weight | ||||||
| | | | | | | |||
inch | mm | mm | bar | psi | bar | psi | kg/m | mm | m |
1 1/4 | 32 | 44 | 10 | 150 | 30 | 450 | 1.2 | 200 | 60 |
1 1/2 | 38 | 51 | 10 | 150 | 30 | 450 | 1.5 | 250 | 60 |
2 | 51 | 64 | 10 | 150 | 30 | 450 | 1.93 | 300 | 60 |
2 1/2 | 64 | 78 | 10 | 150 | 30 | 450 | 2.55 | 350 | 60 |
3 | 76 | 91 | 10 | 150 | 30 | 450 | 3.08 | 460 | 60 |
4 | 102 | 120 | 10 | 150 | 30 | 450 | 4.97 | 600 | 60 |
5 | 127 | 146 | 10 | 150 | 30 | 450 | 6.77 | 700 | 60 |
6 | 152 | 172 | 10 | 150 | 30 | 450 | 8.17 | 800 | 30 |
8 | 203 | 225 | 10 | 150 | 30 | 450 | 12.5 | 1000 | 30 |
